PEEK (Polyether Ether Ketone) Injection Molding Service
PEEK parts offer high strength, high rigidity, and chemical resistance. Elimold’s professional PEEK injection molding service delivers custom high-performance parts in just 5 days. Precise and professional, providing solutions for your demanding needs.
We Are Experts In Precision PEEK Injection Molding
Elimold is an innovator in on-demand digital manufacturing and continues to lead the development of PEEK injection molding and rapid prototyping technologies. We understand how to deliver high-quality PEEK products on time and within budget. Our design philosophy is flexible and efficient, we have a team of experts in PEEK injection molding, and we always adhere to an engineer-centric approach. Tens of thousands of product developers and engineers worldwide trust Elimold to realize their product visions.
Currently, our company continues to expand its expertise in this technology, always committed to providing the best solutions for your (semi-)finished products. Therefore, you can trust us to provide you with customized products and state-of-the-art molding technologies tailored to your company, industry, and application.
Complete Production Support Team
We have a dedicated manufacturing team working behind the scenes to meet your production order needs. We manage the entire process and keep you updated on the latest progress.
Engineering & DFM
Mold Making
Injection Molding
Surface Treatments
Quality and Compliance
Assembly and Shipping
Elimold's Peek Injection Molding Technology: Your Satisfaction Guaranteed
We have invested heavily in establishing industry-leading expertise in PEEK injection molding. With world-class in-house engineering, design, mold making, and machining capabilities, Elimold can work seamlessly with you through all processes, from PEEK mold design to high-volume production and shipping. By continuously refining mold and injection molding processes throughout the development cycle, we can help you optimize the production of PEEK components, creating real value for your business.
What is PEEK (Polyetheretherketone)?
PEEK is a high-strength, semi-crystalline thermoplastic polymer favored for its excellent thermal stability, chemical inertness, and mechanical durability. The chemical structure of PEEK consists of three benzene rings linked by ketone and ether groups. This structure, composed of a repeating sequence of benzene rings linked by ketone and ether groups, gives it a robust and stable semi-crystalline structure.
First synthesized in 1977 and commercially produced in 1981, this material is characterized by its ability to operate continuously at temperatures up to 250°C while maintaining excellent mechanical and electrical properties. Furthermore, it operates reliably in high-pressure water or steam environments up to 300°C. It also exhibits high mechanical strength and rigidity over a wide temperature range, as well as excellent creep resistance and abrasion resistance. Another key characteristic of PEEK is its natural flame retardancy, resulting in a very low risk of producing toxic gases.
Advantages of PEEK in Injection Molding
Superior Strength and Durability
PEEK possesses high tensile strength, high stiffness, and impact resistance, maintaining structural integrity even under heavy loads and harsh conditions.
Low Friction and Abrasion Resistance
PEEK exhibits a low coefficient of friction and excellent abrasion resistance.
Flame Retardant and Low Smoke Emissions
PEEK is inherently flame-retardant, producing extremely low levels of smoke and toxic gases when exposed to fire.
High Thermal Stability
PEEK has a high melting point of approximately 343°C (649°F), maintaining its mechanical properties even at high temperatures.
Excellent Chemical Resistance
PEEK exhibits strong resistance to a wide range of chemicals, including acids, alkalis, and organic solvents.
Biocompatibility
PEEK is biocompatible and can be used in medical applications such as implants and surgical instruments.
PEEK Grades and Variations for Injection Molding
To meet the needs of various industries, we offer a wide range of grades and types of PEEK resin, each designed to optimize performance for specific applications. Choosing the right grade is crucial to balancing mechanical properties, cost, and regulatory compliance. Below are the various grades of PEEK materials we offer.
Unfilled PEEK
This is the base grade of PEEK, offering excellent strength, toughness, and thermal stability. It boasts the highest ductility, making it ideal for many applications requiring precision machining, transparency, or balanced mechanical properties.
Glass Fiber Reinforced Polyetheretherketone
By adding 30% to 40% glass fiber, the stiffness, dimensional stability, and creep resistance of PEEK are significantly improved.
Carbon Fiber Reinforced PEEK
Compared to glass fiber reinforced materials, carbon fiber reinforced materials offer a higher strength-to-weight ratio, better abrasion resistance, and higher thermal conductivity.
Medical-Grade PEEK
Medical-grade PEEK material is specially formulated to meet the International Organization for Standardization/United States Pharmacopeia (ISO 10993, USP Class VI) biocompatibility standards. It exhibits excellent resistance to sterilization (steam, gamma ray, and ethylene oxide sterilization) while mimicking the mechanical properties of human bone.
Conductive/Antistatic PEEK
By adding conductive additives, such as carbon black or special additives, PEEK can achieve controllable surface resistivity, making it suitable for manufacturing electronic components and semiconductor manufacturing equipment, as well as explosive workplaces where electrostatic dissipation is critical.
Bearing PEEK
Bearing PEEK is filled with 20% PTFE and reinforced with graphite-reinforced carbon fibers to reduce the coefficient of friction, thereby improving wear resistance and frictional heat generation capacity.
Custom PEEK
Metal-detectable and X-ray-detectable PEEKs, as well as custom PEEKs, are available. These PEEK types are designed to meet specific customer needs for one or more application functionalities. For example, electrostatic dissipative PEEK is designed for environments requiring non-conductive materials to ensure safety and reliability.
PEEK 450G
PEEK 450G boasts a high tensile strength of 100 MPa, excellent chemical and solvent resistance, and good creep resistance.
PEEK 450GL30
PEEK 450GL30 features a high flexural modulus of 10.0 GPa. The addition of 30% glass fiber enhances its strength and stiffness, while also providing excellent dimensional stability.
PEEK 450CA30
PEEK 450CA30 exhibits a high heat deflection temperature of 280°C. This grade offers enhanced creep resistance, and the addition of 30% glass fiber further strengthens its mechanical properties, improving strength and stiffness.
PEEK 450FC30
PEEK 450FC30 utilizes a solid lubricant formulation to reduce the coefficient of friction. The combination of PTFE and carbon fiber reinforcement improves its wear resistance while retaining PEEK’s chemical resistance.
PEEK 450GUV
PEEK 450GUV’s formulation allows it to withstand ultraviolet (UV) radiation without significant performance degradation. It retains PEEK’s excellent thermal stability, making it suitable for high-temperature environments sensitive to UV radiation. Additionally, it possesses insulating properties.
PEEK 450GRC
PEEK 450GRC is reinforced with carbon fiber, offering exceptional strength and stiffness. The carbon fiber also enhances thermal conductivity, making it highly useful in applications requiring efficient heat dissipation. It maintains excellent dimensional stability even under varying temperature conditions.
PEEK 450CA40
PEEK 450CA40 is designed for high-temperature applications, with a heat deflection temperature of 310°C. It is suitable for components exposed to extreme temperatures. It retains PEEK’s chemical resistance, making it ideal for applications exposed to corrosive chemicals. Furthermore, the addition of 40% glass fiber balances strength, stiffness, and heat resistance.
PEEK 450GC30
PEEK 450GC30 combines the properties of glass fiber and carbon fiber, offering unique advantages such as strength, stiffness, and dimensional stability. This grade of material has a low coefficient of thermal expansion, making it suitable for applications with extremely low requirements for dimensional changes due to temperature variations. It also exhibits excellent chemical resistance.
PEEK 450GFR30
PEEK 450GFR30 is formulated to meet flame retardant standards, making it suitable for applications where fire safety is critical. Despite its flame retardant properties, it retains good mechanical properties, including strength and stiffness. Like other PEEK grades, it exhibits excellent chemical resistance.
Have Any Questions? Our Engineers Are Ready To Assist You
We’d love to do everything we can to help you complete your project. Please contact us, and we’ll reply with the information you need via email or arrange a phone call to discuss it in detail.
Professional PEEK Injection Molding Technology Delivers Consistent Quality and Performance
Our engineers design barrel dimensions based on the material of each PEEK polymer. This minimizes the residence time of the thermoplastic at its melt temperature, preventing material degradation and ensuring that every part we mold maintains the material’s optimal performance. Additionally, we have a specially designed control system for processing high-performance PEEK polymers. During molding, probes are placed in each mold cavity to monitor temperature and pressure to maintain optimal conditions, thus optimizing the quality and performance of every high-temperature polyetheretherketone (HT PEEK) component we produce. An additional feature of Elimold’s injection molding equipment is our injection compression technology. This technology allows us to compress or “imprint” parts while the mold is cooling.
PEEK Custom Injection Molded Parts Reverse Engineering Services
We offer reverse engineering services for your PEEK parts. For your custom PEEK injection molding reverse engineering, our superior service and efficient production ensure timely delivery and high-quality service. In addition to reverse engineering, we also provide emergency manufacturing and delivery, and value-added manufacturing solutions.
Our team of product engineers will quickly provide you with a needs analysis based on your part samples, standards, testing methods, and other requirements. With our strong technical capabilities and extensive experience, we can provide you with one or more solutions, allowing you to ultimately choose the most suitable one.
PEEK Injection Molding Factory
Our factory, located in Shenzhen, China, covers an area of over 10,000 square meters. Our PEEK injection molding production line boasts over 130 fully electric injection molding machines equipped with appropriately sized barrels, minimizing heat treatment time during the PEEK molding process to maximize the performance and consistency of each injection molded part. We have a machine size range from 15 tons to 2200 tons, meaning we can mold PEEK parts ranging in size from 0.1 grams to 3600 grams. All machines are equipped with an RJG system, enabling us to monitor cavity conditions and develop the most reliable PEEK molding processes for specific parts. We apply scientific molding principles to the PEEK injection molding process.
Custom Options for PEEK Injection Molding
Elimold’s professional PEEK injection molding services can meet unique manufacturing needs. Our solutions encompass material grades, mold design, surface treatments, and part geometry. Custom mold designs ensure consistent achievement of complex shapes and tight tolerances (±0.01mm). We offer surface treatment services such as polishing, texture etching, or antistatic coatings. Furthermore, we provide custom color matching and secondary finishing services, such as CNC machining or ultrasonic welding. Our team validates each design through prototyping before full production.
Quality Inspection and Management
Our team understands that quality is key to retaining customers. Before production, our quality inspection team uses a coordinate measuring machine to measure the dimensions of all parts and sends a report for your approval to ensure 100% accuracy. During product manufacturing, quality is most effectively controlled at the machine level. We employ a complete quality control procedure, verifying each step before proceeding to the next production stage. Our quality control department records the production status of each batch to ensure traceability. Furthermore, we provide a complete DFM report before mold making begins, as the quality of the injection mold directly impacts the quality of the molded parts.
Why Choose Elimold?
If you have a new project requiring PEEK molds and related injection molding services, but are unsure if the part structure is suitable for PEEK mold making, please contact us. We will provide you with the best solutions, assisting you in optimizing your design, reducing PEEK mold making costs, and maximizing PEEK mold production. We will help you achieve the greatest commercial return with the lowest possible investment.
If you simply want an initial market assessment estimate, please send us your 3D data (STP or IGS format). You will lose nothing but gain access to our competitive pricing. We will never share your data with any other third party, and we are willing to sign a confidentiality agreement (NDA) to protect your project.
If we manufacture PEEK molded parts for you, we can save you up to 40% on your initial mold investment costs. We will never profit from mold making, and we will not even allocate up to 30% of your project’s mold costs to mold making (depending on your project’s production volume requirements).
Comparison of PEEK and PEI Injection Molding
In the field of injection molding, the core comparison between PEEK and PEI lies in their performance and cost. Both plastics possess similar properties such as high-temperature resistance and corrosion resistance. While their performance is similar, their costs differ significantly (typically, PEEK is 2-3 times more expensive than PEI). Although other plastics (such as PPS and LCP) may be comparable to PEEK and PEI in some aspects, they cannot replace PEEK and PEI in key indicators such as biocompatibility and long-term fatigue strength. Therefore, engineers must weigh performance and cost to select the optimal material.
FAQ
The typical tolerance for PEEK injection molding is ±0.05mm. Achieving precise tolerances depends on a variety of factors, including mold design, machine performance, and processing conditions. Proper mold maintenance and molding parameter control are crucial for consistently achieving the desired tolerances.
PEEK can be overmolded or used in multi-component injection molding, but this requires careful consideration of material and process conditions. Overmolding involves molding a PEEK part onto another material (such as metal or other plastics) to create a composite part with enhanced properties.
The recommended wall thickness for PEEK injection molded parts is typically 1.5mm to 5mm. While thinner wall thicknesses are possible, this requires careful mold design and precise process parameter control to ensure part quality and avoid defects such as warpage or incomplete filling.
We have professional mold designers and experienced technicians, and have introduced over 180 sets of advanced mold manufacturing equipment, with an annual mold production capacity of up to 1300 sets.
For products with low precision requirements, we can provide reverse engineering services based on the sample. However, if you can provide 2D or 3D drawings, it will help us understand your needs more accurately and provide you with a quote faster.
You need to provide 2D and 3D drawings so that we can provide a mold quote and start production faster. We support 2D drawing formats including AI, PDF, DWG, CAD, DXF, DLG, etc. We support 3D drawing formats including STP, STEP, etc.
Our factory strictly adheres to the precision requirements of the drawings you provide for installation and production. We will also communicate with you regarding the mold usage and precision requirements. If the mold does not meet your requirements and is due to a manufacturing problem on our part, our factory will be responsible for arranging rework. However, if the product is scrapped due to errors in your drawings, a separate solution will be required.
Depending on the application requirements, other alternatives can be considered, such as high-performance nylon, polyetherimide (PEI), and polyphenylene sulfide (PPS). However, these materials may not achieve the same superior performance as PEEK.
PEEK materials can maintain their mechanical properties at continuous temperatures up to 260°C. Compared to metals, they offer superior corrosion resistance and lighter weight while providing a similar strength-to-weight ratio.
Contact us For a Quote On Your Custom PEEK Injection Molding Project!
Let us leverage our process expertise to find the most cost-effective PEEK injection molding production solution for you. We can utilize your existing molds or develop new ones.
